4" (102mm) Drop Ball Mount w/ 2.5" (63.5mm) Shank 4500kg

• DROP FORGED FOR EXTREME DURABILITY
• SOLID 63.5MM 2 1/2 INCH SHANK
• REVERSIBLE - RAISES OR LOWERS BALL TO THE RIGHT LEVEL FOR TOWING
• ION FORGED FROM ONE PIECE OF STEEL
• FITS 2.5" X 2.5" TOWBAR RECEIVERS AS FOUND ON SOME US IMPORTS

GROSS TRAILER WEIGHT: 4500KG

TONGUE WEIGHT: 450KG

BALL HOLE SIZE: 1 1/4"  (available is a reducing bush to reduce 1-1/4" to standard 7/8" to suit 50mm tow balls Part No. MHRB

DROP: 102MM

RISE: 63.5MM

LENGTH: 216MM (MEASURED FROM CENTRE OF PIN HOLE TO CENTRE OF BALL HOLE)

SHANK SIZE : 63.5MM / 2-1/2"
