Mister Hitches 285mm Drop Shank

THIS SHANK IS OPTIONAL WHEN EXTRA HEIGHT OR DROP IS REQUIRED FOR YOUR WEIGHT DISTRIBUTION SYSTEM.

SUITS MISTER HITCHES WEIGHT DISTRIBUTION SYSTEMS & MULTI-HITCH MIX 'N' MATCH SYSTEM

MADE FROM SOLID STEEL

INCORPORATES 3 HITCH PIN HOLES FOR GREATER ADJUSTMENT, ALSO CAN SUIT A SHORT SHANK OF A FORD RANGER TOW BAR

PIN HOLES DISTANCE FROM END OF THE SHANK 50MM, 82.5MM AND 125MM

DROP (TOP OF SHANK TO TOP OF WDH BALL PLATFORM) = 135MM

RISE (TOP OF SHANK TO TOP OF WDH BALL PLATFORM)  = 254MM

SHANK OVERALL HEIGHT = 286MM

SHANK IS SOLID STEEL 50.8MM  SQUARE SUITS HAYMAN REESE STYLE TOWBAR RECEIVERS

4.5T RATED - SHANKS ONLY
